Name: TP-Link EAP653 UR OMADA WiFi6 AP (AX3000,2,4GHz/5GHz,1xGbELAN,1xPoE-in)
Brand: TP-link
SKU: 324176
Price: 125.45 EUR
Availability: InStock

TP-Link EAP653 UR OMADA WiFi6 AP (AX3000,2,4GHz/5GHz,1xGbELAN,1xPoE-in)

Kód: 324176

Skladom>5ks

Termín a spôsob doručenia

TP-link

Typ Wi-Fi aktívneho prvku:Acces Pointy, Bridge, MU-MIMO; Komunikačné pásmo:2,4 GHz, 5 GHz, 2,4 + 5 (Dual Band); Podporované štandardy:802.11ax, 802.11b/g, 802.11b/g/n, 802.11a, 802.11b, 802.11g, 802.11a/n, 802.11n, 802.11ac.prečítajte si viac

Vyberte si zvýhodnené balenie

Množstevné zľavy

Váš dotaz

Sledovat

Přístupový bod AX3000 WiFi 6 pro montáž na strop

Velmi rychlé WiFi 6 rychlostí: - 2402 Mb/s na 5 GHz t+ 574 Mb/s na 2,4 GHz

Bezdrátové pokrytí s mimořádným dosahem díky většímu počtu antén s vyšším vysílacím výkonem

Podpora technologií WiFi 6, jako je HE160, 1024-QAM atd

Pokročilé funkce: Omada Mesh, bezproblémový roaming atd

Napájení PoE+: Podporuje standard 802.3at PoE+ i stejnosměrný proud (adaptér není součástí dodávky)

Velmi tenký design: Elegantní design ?16cm × 3,3cm přináší větší agilitu.

Integrace s platformou Omada SDN pro centralizovanou správu

Technické specifikace

HARDWARE FEATURES

Interface

1× Gigabit PoE+ Port

Button

Reset

Power Supply

• 802.3at PoE
• 12V DC / 1.5 A (Power Adapter IS NOT included)
• 48V Passive PoE

Power Consumption

• EU: 14.2 W
• US: 15.5 W

Dimensions ( W x D x H )

6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm)

Antenna Type

Internal Omni
• 2.4 GHz: 2× 5 dBi
• 5 GHz: 3× 5 dBi

Mounting

• Ceiling /Wall Mounting (Kits included)
• Junction Box Mounting

WIRELESS FEATURES

Coverage

140?(1500 ft2)***

Concurrent Clients

250+**

Wireless Standards

IEEE 802.11ax/ac/n/g/b/a

Frequency

2.4 GHz and 5 GHz

Signal Rate

• 5 GHz: Up to 2402 Mbps†
• 2.4 GHz: Up to 574 Mbps†

Wireless Functions

• 1024-QAM
• 4× Longer OFDM Symbol
• OFDMA
• Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• MU-MIMO(2G: 2*2 MU-MIMO DL/UL; 5G:2*2 MU-MIMO DL/UL)
• HE160 (160 MHz Bandwidth)‡
• Seamless Roaming(802.11k/v/r)§
• Omada Mesh§
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client

Wireless Security

• Captive Portal Authentication§
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

Transmission Power

• CE:
<20 dBm(2.4 GHz, EIRP)
<23 dBm(5 GHz, Band1 & Band2, EIRP)
<29 dBm(5 GHz, Band3, EIRP)

MANAGEMENT

Omada App

Yes

Centralized Management

• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Omada Cloud-Based Controller

Cloud Access

Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.

Email Alerts

Yes

LED ON/OFF Control

Yes

Management MAC Access Control

Yes

SNMP

v1, v2c, v3

System Logging Local/Remote Syslog

Local/Remote Syslog

SSH

Yes

Web-based Management

HTTP/HTTPS

L3 Management

Yes

Multi-site Management

Yes

Management VLAN

Yes

Zero-Touch Provisioning

Yes. Requiring the use of Omada Cloud-Based Controller.

OTHERS

Certification

CE, FCC, RoHS

Package Contents

• EAP653 UR
• Ceiling/Wall Mounting Kit
• Installation Guide

System Requirements

Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux

Environment

• Operating Temperature: 0–40 ? (32–104 ?)
• Storage Temperature: -40–70 ? (-40–158 ?)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
